Fluroplastic High Temperature Aircraft Silver Tinned Cable Wire
Applications
Silver or Tinned Aircraft Cable offers excellent corrosion resistance, oil resistance, strong acid/alkali resistance, and oxidation resistance. Features include superior electrical insulation, high voltage resistance, low frequency loss, moisture resistance, and excellent fire resistance with long service life.
Ideal for:
- Electronic industry: temperature compensation wire, low/high temperature heating wire, aging wire, flame retardant wire
- Household appliances: internal wiring for air conditioners, microwave ovens, electronic disinfectors, rice cookers, electric heaters, ovens, frying pans, and lighting
Product Features
- Wear and scratch resistant
- High and low temperature resistant (-65°C to +200°C)
- Anti-aging and corrosion resistant
- Easy to strip
- Anti-interference
Cable Specifications
Insulation: FEP
Conductor: Solid core or stranded silver-plated/tinned copper
Shielding: Tinned copper wire weave shielded
Temperature Range: -65°C to +200°C
Rated Voltage: 600V or 250V
Colors: 10 standard colors (black, brown, red, orange, yellow, green, blue, grey, white, violet)
We also supply PTFE or PFA insulated wire cable.
View PTFE wire optionsProduct Types
| Type |
Description |
| AF-200 |
Silver coated copper conductor FEP insulation hook up wire |
| AF-200-1 |
Tinned copper conductor FEP insulation hook up wire |
| AFP-200 |
Tinned/silver coated copper conductor FEP insulation shield lead wire |
| AFS-200 |
Tinned/silver coated stranded copper FEP insulation twisted lead wire |
| AFSP-200 |
Tinned/silver coated stranded copper FEP insulation twisted shield lead wire |
Detailed Specifications
| Wire Gauge |
Cross-section Area |
Conductor Structure |
Max. OD of Cable (250V) |
Max. OD of Cable (600V) |
| 36AWG |
0.013mm² |
7/0.05 |
0.65mm |
0.85mm |
| 32AWG |
0.035mm² |
7/0.08 |
0.75mm |
0.95mm |
| 30AWG |
0.05mm² |
7/0.10 |
0.85mm |
1.05mm |
| 28AWG |
0.07mm² |
7/0.12 |
0.9mm |
1.1mm |
| - |
0.1mm² |
7/0.14 |
1.0mm |
1.2mm |
| 26AWG |
0.14mm² |
7/0.16 |
1.1mm |
1.3mm |
| 24AWG |
0.2mm² |
19/0.12 |
1.2mm |
1.4mm |
| - |
0.3mm² |
7/0.23 |
1.25mm |
1.48mm |
| 22AWG |
0.35/0.40mm² |
19/0.16 |
1.4mm |
1.6mm |
| 20AWG |
0.5mm² |
19/0.18 |
1.6mm |
1.8mm |
Note: Specifications can be customized beyond these standard options.
Company Information
Factory
Shenzhou Special Cable is a reputed manufacturer of military and consumer cables. Our product range includes:
- High temperature wires/cables (PTFE, FEP, tinned, silver)
- Rubber cables, welding cables, mine cables
- FEP hook up wire, electronic cables
- Power cables, control cables, and more
Team
Our dedicated team includes:
- 5 R&D specialists
- Professional transport team
- Engineering installation team
- 6 international sales staff
- 15 domestic sales staff
- 10 quality control specialists
Workshop
Production Capacity:
• 9 production lines
• 90,000m monthly capacity
• 250 production workers
• RMB20 million annual capacity
• Advanced testing equipment
Warehouse
• 600+ square meters storage
• Also produces:
- Low smoke zero halogen compounds
- XLPE compounds
- Soft PVC compounds for cable insulation/sheath
Quality Assurance
We maintain strict quality control throughout manufacturing. Our warranty covers repair, replacement, or return for any products with manufacturing defects, plus compensation for related economic losses.
Our Customers
With over 20 years experience, we've exhibited at Middle East Electricity Exhibition (Dubai), China-ASEAN Exposition, Power-Gen India, and more. Our professional service ensures successful partnerships.
Why Choose Us
Quality Comparison
| Item |
Faulty Products |
Our Products |
| Length |
Insufficient |
Sufficient |
| Wire Drawing |
Thick ends, thin middle |
Consistent throughout |
| Conductor |
Copper clad aluminum/brass |
99.999% pure copper |
| Insulation |
Recycled compound |
Virgin compound |
Our Services
- Free technical consultation before, during, and after sales
- Free samples and design services
- Special monitoring during manufacturing
- 100% free internal transportation insurance
- OEM/ODM services available
- Small order quantities accepted
Packaging Options
Standard Packaging:
• 100m/coil with non-woven bag
• 200m/roll with film
• 500m with wooden drum
• 800m with wooden iron drum
Custom Options:
• Polyethylene film winding with non-woven bag/carton (100m/roll)
• Plastic tray drums (300m/drum)
• Fumigated wooden drums available with certificate
• Shipping by sea, train, or express as required
Frequently Asked Questions
1. Are you a manufacturer or trading company?
We are a professional manufacturer of military and consumer cable wire and cable compounds, located in Hunan Province, China.
2. What are your company's strengths?
As a stable supplier to China's aerospace and military sectors with 21 years experience, we produce our own cable compounds to maintain superior quality and competitive pricing.
3. How do you guarantee product quality?
Quality is our top priority with strict controls at every stage: design, material procurement, manufacturing, semi-finished testing, and final inspection.
4. What's your product warranty?
We provide a 1-year warranty with unconditional replacement or return for any quality issues.
