| Conductor Materials | Silver Plated Copper, Tinned Plated Copper, Bare Copper |
|---|---|
| Conductor Type | Stranded or Solid |
| Insulation | PTFE, FEP, PFA Insulated |
| Number Core | Single Core or Multiple Cores |
| Size | 0.05~3mm² |
| Rated Voltage | 600V or Below |
| Rated Temperature | -80°C to +250°C |
| Color | White, Blue, Red, Black, Yellow, Green, Transparent, Yellow/Green |
| Type | Name |
|---|---|
| AF-200 | Silver plated copper wire conductor high temperature FEP insulated wire |
| AF-200-1 | Tinned copper wire conductor high temperature FEP insulated wire |
| AFP-200 | Tinned copper wire or silver plated copper wire core FEP insulated shielding wire |
| AFS-200 | Tinned copper wire or silver plated copper wire core FEP insulated stranded cable |
| AFSP-200 | Tinned or silver coated copper FEP insulated stranded shielding cable |
| AFR-200 | Bare Copper wire conductor PTFE film insulated lead wire |
| AFR-250 | Silver plated copper wire conductor PTFE film insulated lead wire |
| AFP | Bare Copper wire conductor PTFE film insulated screen lead wire |
| AFP-1 | Silver plated copper wire conductor PTFE film insulated screen lead wire |
| AFRP-200 | Bare Copper wire conductor PTFE film insulation shield lead wire |
| AFRP-250 | Silver plated wire copper conductor PTFE film insulation shield lead wire |
| AFRPF-250, AFPF | Silver plated wire copper conductor PTFE film insulation PTFE film sheath shield lead wire |
| Nominal Section (mm²) | Conductor Construction (No/mm) | Insulation Thickness (mm) | Outer Diameter (mm) | D.C. conductor resistance at 20°C (Ω/km) |
|---|---|---|---|---|
| 0.05 | 10/0.08 | 0.3 | 0.9 | 383 | 370 |
| 0.06 | 7/0.10 | 0.3 | 0.9 | 348 | 339 |
| 0.08 | 7/0.12 | 0.3 | 0.96 | 286 | 280 |
| 0.1 | 7/0.14 | 0.3 | 1.02 | 157 | 150 |
| 0.12 | 7/0.15 or 30/0.07 | 0.3 | 1.05 | 152 | 145 |
| 0.14 | 7/0.16 or 19/0.10 | 0.3 | 1.08 | 136 | 130 |
| 0.15 | 30/0.08 | 0.3 | 1.1 | 111 | 105 |
| 0.2 | 7/0.02 or 19/0.12 | 0.3 | 1.2 | 87 | 82 |
| 0.35 | 19/0.16 | 0.3 | 1.4 | 57 | 54 |
| 0.5 | 19/0.18 | 0.3 | 1.5 | 40 | 37.5 |
| 0.8 | 19/0.23 | 0.32 | 1.79 | 24 | 23 |
| 1 | 19/0.26 | 0.35 | 2 | 21 | 20 |
| 1.2 | 19/0.28 | 0.45 | 2.3 | 19 | 18 |
| 1.5 | 19/0.32 | 0.45 | 2.5 | 13 | 12 |
| 2 | 19/0.37 | 0.45 | 2.75 | 10 | 9 |
| 2.5 | 37/0.30 | 0.55 | 3.2 | 8 | 7 |
| 3 | 37/0.32 | 0.68 | 3.6 | 6.8 | 6.4 |
